TCR Heavy Duty Air Hoist TCR Pendant Control

  1. Technical Info
  2. TCR Heavy Duty Air Hoist
  3. TCR Pendant Control

TCR Line drawing

Pneumatic Motorized Trolley Mount Dual Fall (pendant control); *For informational purposes only, contact Kito for dimensional drawing

Dimensions

Capacity (tonne) Model C (in.) F a b e g h k n r t
1/4 TCRM250P 19.3 2.28~5 493 396 262 30 94 122 112 51 30
1/2 TCRM500P 19.3 2.28~5 493 396 262 30 94 122 112 51 30
1 TCRM1000P2 21.5 2.28~5 493 396 262 30 94 122 112 51 30
1 TCRM1000P 19.5 2.28~5 493 396 262 30 94 122 112 51 30
2 TCRM2000P2 23.3 3.94~6 533 442 267 30 124 127 140 71 43

* All measurements in millimeters (mm) - except headroom (C-inches) . Please confirm specifications with technical support before purchase.

Specifications

Capacity (tonne) Model Standard Lift (ft) Cord L (ft) Speed (ft/min @ 90 psi) Up/Down Rates (Cubic ft/min @ 90 psi) Up/Down Consumption Traversing Speed (ft/min) Minimum Radius For Curved (mm) Load Chain Diameter (mm) x Chain Fall Lines Net Weight (Lbs) Weight For Additional 5ft of lift (Lbs)
w/NO Load w/Full Load TCR MCR w/Full Load+NO Load
w/NO Load w/Full Load
1/4 TCRM250P 10 6 68/44 52/51 63/49 48/57 53 65 3500 6.3 x 1 170 3
1/2 TCRM500P 10 6 68/44 37/57 63/49 48/57 53 65 3500 6.3 x 1 170 3
1 TCRM1000P2 10 6 34/22 19/29 63/49 48/57 53 65 3500 6.3 x 2 183 6
1 TCRM1000P 10 6 37/22 21/33 62/53 53/60 53 65 3500 7.1 x 1 209 4
2 TCRM2000P2 10 6 18.5/11 11/16 62/53 53/60 53 65 1300 7.1 x 2 254 7.5
