TCR Line drawing
Plain Trolley Mount Dual Fall (pendant control); *For informational purposes only, contact Kito for dimensional drawing
Capacity (tonne) | Model | Headroom C | F | a | b | e | g | h | k | n | r | t |
---|---|---|---|---|---|---|---|---|---|---|---|---|
1/4 | TCRP250P | 18.6 | 2~4 | 203 | 183 | 46 | 28 | 81 | 76 | 84 | 38 | 22 |
1/2 | TCRP500P | 18.6 | 2~4 | 203 | 183 | 46 | 28 | 81 | 76 | 84 | 38 | 22 |
1 | TCRP1000P2 | 21.3 | 2.3~5 | 249 | 236 | 56 | 28 | 106 | 94 | 112 | 51 | 25 |
1 | TCRP1000P | 19.2 | 2.3~5 | 249 | 236 | 56 | 28 | 106 | 94 | 112 | 51 | 25 |
2 | TCRP2000P2 | 21.9 | 3.3~6 | 300 | 280 | 69 | 28 | 127 | 112 | 132 | 61 | 32 |
* All measurements in millimeters (mm) - except headroom (C-inches) . Please confirm specifications with technical support before purchase.
Capacity (tonne) | Model | Standard Lift (ft) | Cord L (ft) | Speed (ft/min @ 90 psi) Up/Down | Rates (Cubic ft/min @ 90 psi) Up/Down Air Consumption | Load Chain Diameter (mm) x Chain Fall Lines | Net Weight (Lbs) | Weight For Additional 5ft of lift (Lbs) | ||
---|---|---|---|---|---|---|---|---|---|---|
w/NO Load | w/Full Load | w/NO Load | w/Full Load | |||||||
1/4 | TCRP250P | 10 | 6 | 55/41 | 27/54 | 32/25 | 25/28 | 4 x 1 | 76 | 4 |
1/2 | TCRP500P | 10 | 6 | 62/43 | 33/53 | 60/49 | 49/57 | 6.3 x 1 | 76 | 4 |
1 | TCRP1000P2 | 10 | 6 | 31/21 | 16/26 | 60/49 | 49/57 | 6.3 x 2 | 94 | 8 |
1 | TCRP1000P | 10 | 6 | 34/21 | 19/30 | 60/53 | 49/60 | 7.1 x 1 | 91 | 5 |
2 | TCRP2000P2 | 10 | 6 | 17/10 | 10/15 | 60/53 | 49/60 | 7.1 x 2 | 113 | 10 |
